Improve soil health by Stealth
It is widely acknowledged that reducing the mixing of soil horizons will improve soil health and it is also well documented that reduced surface disturbance is essential in fighting grassweeds.
Where a min till or no till regime is employed, either constantly or during the rotation, there is a growing demand for effective, low disturbance subsoiling to loosen and fracture the medium depth subsoil to relieve compaction thus assisting drainage, aeration, nitrogen uptake and encouraging crop rooting.
GRANT ELIGIBILITY
As the application deadline has ended, now is the time to secure your purchase!
Subsoiler
Investment item: Subsoiler
Eligible Item: Stealth
Specification:
- minimum working width of 2.7m
- minimum two legs
- cutting disc preceding each subsoil leg
- rear roller for consolidation
- depth control
The grant will be a maximum 40% contribution against actual invoiced costs up to the maximum referenced costs as stated within Annex A.
If you're interested in this machine, the first step is to apply for the eligible machine before the 16th April 2024. Secondly, once you have your application approved, and you’ve accepted the contract within 30 calendar days of the offer date and adhered to all the requirements, the next step is to purchase the item/machine.
If your application for the above machine is successful, then speak to your local HE-VA dealer in good time, to ensure timely delivery within 6 months of the submission of the claim. Find your local HE-VA dealer here.
Taking on board customer feedback and keeping soil health a priority, OPICO (HE-VAs distributor in the UK) have worked closely with HE-VA in Denmark to design a totally new low-disturbance subsoiler specifically for the UK market. HE-VA have over 15 years of expertise in producing subsoilers coupled with the past five years of manufacturing low disturbance subsoiling machines.
The HE-VA Stealth is a medium depth, low disturbance subsoiler., its scalloped straight, front cutting discs cut through trash, vegetation and top soil, reduce soil burst and in turn grassweed germination.
The Stealth's low disturbance legs are staggered in 2 rows to allow residue flow through the machine to reduce the required tractor lift capacity whilst maintaining a lower HP requirement. Leg spacing is standard at 500mm but can be altered to 450mm, 500mm or 550mm, adding versatility for differing soil types and conditions.
The 15mm hardened cast steel low disturbance points are tungsten tipped and 120mm wide creating the necessary lift and shatter whilst ensuring longevity. Similarly, the 15mm leg is thinner than a standard subsoiler leg but, being made from “Hardox” gives it strength and durability.
Surface compaction can be alleviated to a maximum working depth of 300mm (12”). HE-VA’s standard hydraulic depth control is fully adjustable from the tractor seat.
The Stealth has been designed to satisfy the requirements of no till and reduced input farming systems. However, it is also suitable for use in all farming systems where repair to damaged soil structure is required e.g. on headlands, tramlines or other high traffic areas.
The Stealth is available as a 3m and 3.5m, rigid, linkage mounted machine or 4m, 5m and 6m hydraulic folding, linkage mounted or trailed machines.
A Stealth kit i.e. legs and points are available to retro fit to existing HE-VA machines e.g. the HE-VA Subsoiler range, HE-VA Combi-Disc, Evolution and Combi-Lift.
FEATURES & BENEFITS
Stealth 15mm LD Legs & Points
The Stealth 15mm low disturbance leg and tungsten tipped LD point are also the product of many years development. Whilst many customers are moving towards reduced tillage systems they appreciate that drainage is key to crop development, allowing timely field operations and preventing the relentless progress of grass weeds such as blackgrass.
The Stealth 15mm low disturbance leg and point that HE-VA has developed allows sub-soil conditioning whilst minimising surface disturbance and preventing mixing of the soil profile.
The thinner legs are made from stronger Hardox steel. However, it is the point that really makes the difference. The Stealth point has a shallower wing angle and tungsten tipped nose that opens the soil to create drainage without disturbing the whole soil profile.
V Profile Rear Rollers
Like many of the machines in the HE-VA range the Subsoiler uses the pressed steel V profile ring as standard. However, all the rings are mounted on a 300mm tube so that each section of the roller turns as one ensuring the machine can continue to work in very wet sticky conditions.
Each ring section is castellated ensuring the roller turns in light soils and the aggressive rib and shoulder profile combines with the 125mm spacing to leave an excellent consolidated weatherproof finish.
Front Cutting Discs
Scalloped, straight front cutting discs cut through the surface ahead of low disturbance legs to minimise soil burst and in turn grassweed germination.
Shearbolt Leg Protection
The Subsoiler “Hammer Thru” quick change shearbolt system protects the machine in tough, stony conditions and means minimum down time for the operator. Its “toblerone style” shearbolt allows several resets before the need for a change.
When the legs brake back the operator simply removes the holding pin and hammers another segment of the shearbolt through then returns the holding pin to its original position. This removes the need to carry a supply of shearbolts while using the Stealth low disturbance subsoiler.
Alternatively there is a Hydraulic Reset Subsoiler version for extremely stony conditions.
Hydraulic Auto Rest Leg Protection
All models are available with hydraulic auto reset for extremely stony conditions. An individual hydraulic cylinder on each leg which is connected to a gas accumulator allows the leg to break back and reset if it comes into contact with an unmovable object.
As the legs on a Stealth low disturbance subsoiler are adjusted deeper the leverage on the hydraulic reset cylinder increases and so a pressure gauge is used to allow the operator to set the force required for the leg to break back.
DEPTH CONTROL
Hydraulic Depth Control
The HE-VA Stealth subsoiler hydraulic depth control is a useful feature making it easy for the operator to alter the working depth – for example to work the Subsoiler deeper up the tramlines or in habitually water logged areas.
It also simplifies hitching and unhitching the Stealth subsoiler from the tractor.
Disc Depth Marker
Depth markers are fitted to all new Stealth subsoilers to show the position for the front leading disc as standard. There will be a single marker fitted to in the right hand side of all width machines.
STEALTH MODELS
The Stealth shearbolt models are available in 3m, 4m, 5m and 6m with 6, 7, 8, 10, and 12 legs respectively. The 3m and 3.5m come as rigid frames whilst the 4m-6m are folding.
Technical Information
| Model | Description | Frame | Std. No. Legs | Max HP | Roller |
| 1064480-21 | 3m mounted Stealth | Rigid | 6 | 300hp | V-Profile |
| 1064480-31 | 3.5m mounted Stealth | Rigid | 7 | 300hp | V-Profile |
| 1064480-41 | 4m mounted Stealth | Folding | 8 | 450hp | V-Profile |
| 1064480-81 | 4m trailed Stealth | Folding | 8 | 450hp | V-Profile |
| 1064480-51 | 5m mounted Stealth | Folding | 10 | 450hp | V-Profile |
| 1064480-91 | 5m trailed Stealth | Folding | 10 | 450hp | V-Profile |
| 1064480-61 | 6m mounted Stealth | Folding | 12 | 450hp | V-Profile |
| 1064480-01 | 6m trailed Stealth | Folding | 12 | 450hp | V-Profile |
Hydraulic Auto-Reset Stealth Subsoiler
The hydraulic auto reset models are available in 3m, 4m, 5m and 6m with 6, 7, 8, 10, and 12 legs respectively. The 3m and 3.5m come as rigid frames whilst the 4m-6m are folding.
Technical Information
| Model | Description | Frame | Std. No. Legs | Max HP | Roller |
| 1064480-26 | 3m mounted Stealth | Rigid | 6 | 350hp | V-Profile |
| 1064480-36 | 3.5m mounted Stealth | Rigid | 7 | 350hp | V-Profile |
| 1064480-46 | 4m mounted Stealth | Folding | 8 | 450hp | V-Profile |
| 1064480-86 | 4m trailed Stealth | Folding | 8 | 450hp | V-Profile |
| 1064480-56 | 5m mounted Stealth | Folding | 10 | 450hp | V-Profile |
| 1064480-96 | 5m trailed Stealth | Folding | 10 | 450hp | V-Profile |
| 1064480-66 | 6m mounted Stealth | Folding | 12 | 450hp | V-Profile |
| 1064480-06 | 6m trailed Stealth | Folding | 12 | 450hp | V-Profile |
OPTIONS & ACCESSORIES
Precise OSR seed and slug pellet metering through a single control box. It accurately applies seed and slug pellets in the same pass, making the Multi-Seeder Twin the ideal OSR seeder.
Simple calibration and rate setting - easy to set up
• Individual metering for each outlet - precision
• Failsafe operator alarms - peace of mind
• Bespoke HE-VA machine fitting kits - no compromise
• RDS control box
• Radar - Accurate forward speed measurement
• Quick empty chute.
| Model | Frame | Description |
| 1064485-02 | Rigid | Multi-Seeder fitting kit 6 leg rigid (band seeding) |
| 1064485-06 | Rigid | Multi-Seeder fitting kit 7 leg rigid (band seeding) |
| 1064485-62 | Rigid | Multi-Seeder fitting kit 6 leg rigid (broadcast seeding) |
| 1064485-66 | Rigid | Multi-Seeder fitting kit 7 leg rigid (broadcast seeding) |
| 1064485-95 | Rigid | Platform and step for Multi-Seeder |
| 1064485-13 | Folding | Multi-Seeder fitting kit 8 leg mounted (band seeding) |
| 1064485-17 | Folding | Multi-Seeder fitting kit 10 leg mounted (band seeding) |
| 1064485-21 | Folding | Multi-Seeder fitting kit 12 leg mounted (band seeding) |
| 1064485-73 | Folding | Multi-Seeder fitting kit 8 leg mounted (broadcast seeding) |
| 1064485-77 | Folding | Multi-Seeder fitting kit 10 leg mounted (broadcast seeding) |
| 1064485-81 | Folding | Multi-Seeder fitting kit 12 leg mounted (broadcast seeding) |
| 1063099-50 | Folding | Ladder, platform and step for Multi-Seeder |
The HE-VA Accu-Disc is a double disc coulter with press wheel, this is the next step in Till-Seeding enabling seed placement to be controlled precisely and consistently to your required depth.
The Accu-Disc coulters are placed in line with the tines, once the tine has passed through and created some tilth on the surface and the roller has re-consolidated the soil the Accu-Disc coulter opens the soil and places the seed at a constant depth ensuring no seed is visible on the surface then the rear press wheel closes and re-consolidates ensuring good seed to soil contact.
Rigid and folding optional extras
| Model | Frame | Description |
| 1064484 | Rigid Mounted | Additional complete leg & disc (factory fit only) |
| 1064484-00 | Folding Mounted | Additional complete leg & disc (factory fit only) |
| 1064484-00 | Folding Trailed | Additional complete leg & disc (factory fit only) |
